Features & Benefits
1Commercial Downlight Retrofit or New Construction
Universal Voltage 120-277V
UL for Safety, Wet-Location Rated
Three Adjustable Lumen Output
Three Adjustable CCT Options (3000K, 3500K, 4000K)
High CRI
Long Life
Convenient and quick installation
0-10V Dimmable
25" Flexible Conduit
Works in cold temperature applications
Flicker-free, Meets IEEE 1798-2015
5 Year Warranty


VEKR6D/9T/21W-10V TAA
Commercial Recessed Downlight
BAA/TAA Compliant

Specification Data
Model No. Size IC Rated Watts Lumens CCT Efficacy Input Voltage CRI Power Factor Dimension
VEKR6D/9T/21W-10V TAA6 in RecessYes9.5 / 13.5 / 21770 / 1050 / 15003000K, 3500K, 4000K selectable81 / 78 / 71120-277900.9Dia. 8.27 in x Height 4.25 in
Ordering Information
Sample model: VEKR4D/9T/14W-10V BAA
  VEKR 4D 9T 14W 10V BAA


Series

Retrofit Kit
Recessed Light

Size

4"
Downlight

CRI>90

T: three CCT
adjustable

Wattage

14W Max.

Dimming

0-10V

COO

BAA

TAA
User Manual 468inDownlightInstallation.pdf
