CoreTech Type C PL Lamp CCT Selectable

Commercial Grade LED T8 Lamp

CLD18WV/8T-XT

CLD18WV/8T-XT

Descriptions:

The CORETECH Type C PL series LED lamp provides perfect solution for new and retrofit kit application with standard G24D base compact fluorescent. It is deisgned to use in existing fixture and approved for use in open fixtures. The CCT switch allows 3-CCT selectable in the field. The Type C PL LED lamp is compatible with Class 2 LED driver using various control abilities, it is suitable for damp location including walkways & pathways, corridors, general indoor lighting, residential, commercial and industrial areas.

Features & Benefits:

  • Field selectable 3000K, 3500K, 4000K color temperatures.
  • Color rendering index > 80, R9 > 0.
  • Operating Temperature: -20° to 130° F.
  • FCC CFR 47, GCC Part 15, Subpart B:2017.
  • Utilizes G24D base.
  • Dimmable using compatible driver.
  • Frosted to Prevent Glare.
  • Average life (L70) of 70,000 hours.

Specifications:

Ordering Code Lamp Current Lamp
Wattage
System Wattage

CCT

(K)

Initial
Lumens
CRI Lamp
Efficacy
System Efficacy
CLD18WV/8T-XT250mA67.53000K (selectable)7008011793
CLD18WV/8T-XT250mA67.53500K (selectable)7408012399
CLD18WV/8T-XT250mA67.54000K (selectable)75080125100
CLD18WV/8T-XT300mA7.593000K (selectable)8508011394
CLD18WV/8T-XT300mA7.593500K (selectable)91080121101
CLD18WV/8T-XT300mA7.594000K (selectable)93080124103
CLD18WV/8T-XT360mA910.53000K (selectable)10208011397
CLD18WV/8T-XT360mA910.53500K (selectable)108080120103
CLD18WV/8T-XT360mA910.54000K (selectable)111080123106

Wiring Diagram:

DLC Listing:

Ordering Code DLC Product ID DLC Product Model DLC Version
CLD18WV/8T-XTNA
CLD18WV/8T-XTNA
CLD18WV/8T-XTNA
CLD18WV/8T-XTNA
CLD18WV/8T-XTNA
CLD18WV/8T-XTNA
CLD18WV/8T-XTNA
CLD18WV/8T-XTNA
CLD18WV/8T-XTNA



Specification data is based on tests performed in a controlled environment and represents relative performance. Actual performance can vary depending on operating conditions. Application and performance data subject to change without notice. All specifications are nominal unless noted otherwise.
